| 型號 Model： 6M20-284/25 壓縮介質 Compression Medium： 焦?fàn)t氣 Coke-oven gas 冷卻方式 Cooling style: 水冷 water cooling 氣缸潤滑方式 Cylinder Lube style: I,II級有油，III, IV無油 I and II with oil lube, the III and IV with oil free. 列數 No. of throw: 6 壓縮級數 Compression stage: 4 排氣量 Capacity (m3/min): 284 吸氣壓力 Suction pressure (MpaG): 0.025 排氣壓力Discharge pressure (MpaG): 2.5 主機外形尺寸 Outline dimension (L×W×H)(mm): 8122×6146×2366 主機重量 Main unit weight (Kg): 160000
驅動電機 Driven motor: 增安型無刷勵磁同步電機 功率:2400KW
|
